Super powerful engine
1.The crew is started by a well-known engine, achieving high power output, high torque, and easy maintenance
2.A compact structure with multiple internal isolators, small size, strong power, reliable functionality, and long working life
3.Widely using electronic speed controllers, the frequency regulation rate of the unit changes from no load to 10% load by less than 1%
4.The intercooler rapidly cools the high-temperature gas compressed by the turbocharger, thereby improving the combustion efficiency of the engine, increasing the power of the unit, and reducing carbon dioxide emissions
High performance
1.Generator H-level insulation, IP23 (or NEMA1) protection level, brushless self-excited, 4-pole rotating magnetic field, single bearing, etc. Most units are equipped with AVR, which has high performance with voltage fluctuation rate within+0.5% and speed variation rate within 5%
2.Equipped with sufficient damping coils, the voltage fluctuation deformation is minimal, and it can be directly used as a variable frequency load, enabling the unit to quickly recover from frequency fluctuations at any moment of loading
3.The load ranges from 0-100%, with a frequency fluctuation rate of+0.25%
4.Three phase balanced load, with maximum waveform distortion rate of line voltage not exceeding 5%
Modular operation of microcomputers
1.The controller integrates digitalization, intelligence, and networking, with a microprocessor as the core and a computer control, regulation, and monitoring system
2.Multiple languages to choose from
3.Display the performance status of the entire system to ensure efficiency, reliability, and self-protection
4.Automatic control, economical operation
5.Can be equipped with ATS for automatic connection and switching with mains power, or multiple units in parallel, easy to operate
Oil supply and shock absorption device
1.The unit is equipped with a large capacity daily base oil tank, and is equipped with convenient refueling ports and oil level monitoring systems
2.The electric ball, engine, and unit base are all equipped with shock-absorbing rubber pads, which further reduce vibration and greatly extend the service life of the unit
Highly secure
1.The design, production, and testing of the unit fully comply with national standards and European CE safety standards
2.Equipped with monitoring system and emergency stop device, the alarm adopts diode lighting method, which is durable and reliable
3.Equipped with an emergency shutdown circuit for the engine, it completely eliminates the risk of electric shock during restart
4.Equipped with protective covers for fan operating parts, etc., to prevent scalding and ensure the safety of operators
